Metric 7000 Series Single Mounting Duplex Mounting Angular Contact Ball Bearings
- Product Code: 7000 ~ 7040
- Availability: In Stock
This product has a minimum quantity of 100
Bearing Type: Axial and Radial Ball Bearings
Construction: Single Row
Materials: Chrome Steel(GCr15/SAE52100) or Stainless Steel(440/316/304)
Seal Type: Open, ZZ(Metal Shields), 2RS(Rubber Seals)
Tolerance: P0(ABCE-1), P6(ABCE-3), P5(ABCE-5), P4(ABEC-7), P2(ABCE-9)
Clearance: C0, C2, C3
Noise: Z, Z1, Z2, Z3
Vibration: V, V1, V2, V3
Temperature Range: -30° to 110 °C
| Bearing No. | Bore Diameter Range (mm) | Mounting Type | Contact Angle |
| 7000 ~ 7040 | 10 ~ 200 | Single Mounting | 30° |
| 7000DB ~ 7040DB | 10 ~ 200 | DB(Back to Back) Mounting | 30° |
| 7000DF ~ 7040DF | 10 ~ 200 | DF(Face to Face) Mounting | 30° |
| 7000DT ~ 7040DT | 10 ~ 200 | DT(Tandem) Mounting | 30° |
| 7000C ~ 7040C | 10 ~ 200 | Single Mounting | 15° |
| 7000CDB ~ 7040CDB | 10 ~ 200 | DB(Back to Back) Mounting | 15° |
| 7000CDF ~ 7040CDF | 10 ~ 200 | DF(Face to Face) Mounting | 15° |
| 7000CDT ~ 7040CDT | 10 ~ 200 | DT(Tandem) Mounting | 15° |
